GPERx6
Photographs: MikroTik Canada store, standardised on a white canvas with the MikroTik Canada watermark. Originals and permissions are recorded.
Product code: CSS606-1G-2Gi-3S+OUT
Switches: Gigabit Ethernet ports, SFP+ cages, PoE output.
Availability: see the store.
Specifications
| Item | Value |
|---|---|
| Switch chip model | 88E6193X |
| Operating System | SwOS |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
| CPU temperature monitor | Yes |
| Certification | CE, EAC, ROHS |
| IP | 66 |
Powering
| Item | Value |
|---|---|
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input Voltage | 12-57 V |
| Max power consumption | 160 W |
| Max power consumption without attachments | 6 W |
| PoE in | 802.3 bt |
| Cooling type | Passive |
| PoE in input Voltage | 42-57 V |
| PoE-out ports | Ether2-Ether3 |
| PoE out | Passive PoE up to 57V |
| Low voltage PoE-Out current limit | 1.2 A |
| High voltage PoE-Out current limit | 0.625 A |
| Max total out (A) | 2.4 A |
| Total output power | 150 |
Ethernet
| Item | Value |
|---|---|
| 10/100/1000 Ethernet ports | 3 |
| Number of 1G Ethernet ports with Reverse PoE (PoE-in) | 1 |
| Number of 1G Ethernet ports with PoE-out | 2 |
Fibre
| Item | Value |
|---|---|
| SFP+ ports | 3 |
Benchmarks
Switching results
| Mode | Configuration |
|---|---|
| Switching | Non blocking Layer 2 throughput |
| Switching | Non blocking Layer 2 capacity |
| Switching | Non blocking Layer 1 throughput |
| Switching | Non blocking Layer 1 capacity |
MikroTik states that results show maximum performance in the stated test configuration and that other configurations most likely give lower results. Source: MikroTik official product page, retrieved 2026-10-02.
Included in the box
As listed by MikroTik. These come with the product and are not ordered separately.
- K-93
- Hose clamp 2
Optional purchases (sold separately)
No separately orderable accessories were matched to this product in the catalogue. Accessories and spare parts are in the Accessories group and in the store.
Documents
Datasheets and brochures
- Brochure (MikroTik)
Guides and manuals
- User manual (MikroTik)
Diagrams and dimensions
- Block Diagram (MikroTik)
Certificates and compliance
- Declaration of conformity (MikroTik)
Other documents
- Safety and regulatory information (MikroTik)
Source: MikroTik official product page, retrieved 2026-10-02. Items MikroTik does not list are unknown, not zero.
