GPEN21
Photographs: MikroTik Canada store, standardised on a white canvas with the MikroTik Canada watermark. Originals and permissions are recorded.
Product code: GPEN21
Accessories: Gigabit Ethernet ports, SFP cages, PoE output.
Availability: see the store.
Specifications
| Item | Value |
|---|---|
| Switch chip model | 88E6341 |
| Operating System | SwitchOS Lite |
| Input voltage | 12 - 57 V, Passive or 802.3af/at |
| MTBF | Approximately 100'000 hours at 25C |
| Tested ambient temperature | -20°C to 70°C |
| Output Voltage | Yes, Passive PoE up to 57 V |
| Mode button | Yes |
| Certification | CE, EAC, ROHS |
| IP | IP20 |
Powering
| Item | Value |
|---|---|
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input Voltage | 12-57 V |
| Max power consumption | 30 W |
| Max power consumption without attachments | 3 W |
| PoE in | 802.3af/at |
| Cooling type | Passive |
| PoE in input Voltage | 12-57 V |
| PoE-out ports | Ether2 |
| PoE out | Passive PoE up to 57V |
| Low voltage PoE-Out current limit | 850 mA |
| High voltage PoE-Out current limit | 625 mA |
| Max total out (A) | 850 mA |
Ethernet
| Item | Value |
|---|---|
| 10/100/1000 Ethernet ports | 2 |
| Number of 1G Ethernet ports with PoE-out | 1 |
Fibre
| Item | Value |
|---|---|
| SFP ports | 1 |
Included in the box
As listed by MikroTik. These come with the product and are not ordered separately.
- K-62 kit
Optional purchases (sold separately)
No separately orderable accessories were matched to this product in the catalogue. Accessories and spare parts are in the Accessories group and in the store.
Documents
Datasheets and brochures
- Brochure (MikroTik)
Guides and manuals
- Quick Guide (MikroTik)
- Quick Guide (2) (MikroTik)
- User Manual (MikroTik)
Diagrams and dimensions
- Mounting dimensions (MikroTik)
Certificates and compliance
- Declaration of conformity (MikroTik)
Other documents
- GPEN concept (MikroTik)
Source: MikroTik official product page, retrieved 2026-10-02. Items MikroTik does not list are unknown, not zero.
